lippert level up manual

The Lippert Level-Up System is an automatic hydraulic leveling solution designed for RVs, offering one-touch leveling for 5th wheels. It features a 12V DC power supply, a hydraulic pump, and a network of hoses and jacks to stabilize the coach, available in 4-point or 6-point configurations.

1.1 Overview of the Lippert Level-Up Automatic Leveling System

The Lippert Level-Up System is an electric/hydraulic leveling solution designed for RVs, including 5th wheels and motorhomes. It features a 12V DC power supply, a hydraulic pump, and a network of hoses and jacks to stabilize the coach. Available in 4-point or 6-point configurations, it offers one-touch automatic leveling and manual control options for precise adjustments, ensuring efficient and stable setup on any terrain.

1.2 Key Features and Benefits of the Level-Up System

The Level-Up System offers automatic one-touch leveling, manual control for precise adjustments, and compatibility with 4-point or 6-point configurations. It features hydraulic jacks with high lifting capacity, a 12V DC power supply, and a user-friendly control panel. Benefits include reduced setup time, enhanced stability, and safety. The system is designed for 5th wheels and motorhomes, ensuring efficient leveling on various terrains while providing a stable and secure environment for RV owners.

Installation and Setup

The Level-Up System requires professional installation, ensuring proper connection of hydraulic components and control panels. Follow the manual for detailed steps and parts list guidance.

2.1 Step-by-Step Installation Guide for the Level-Up System

• Park the RV on level, firm ground and ensure all jack locations are clear of debris.
• Connect the hydraulic components and control panel as per the manual.
• Test the system to ensure proper function before full deployment.

2.2 Pre-Installation Checks and Requirements

• Ensure the RV is parked on solid, level ground to prevent instability during installation.
• Verify all jack landing points are free from debris and obstructions for proper placement.
• Check system compatibility with your RV configuration (4-point or 6-point setup).
• Confirm the 12V DC power supply is correctly connected and functioning;
• Review the manual to ensure all components are included and undamaged.
• Consider professional installation if unfamiliar with hydraulic systems.

Operating Modes

The Lippert Level-Up System features two primary operating modes: Auto Mode for one-touch leveling and Manual Mode for precise control of individual jacks, ensuring flexibility and accuracy.

3.1 Auto Mode: One-Touch Leveling

The Auto Mode provides a quick and efficient way to level your RV. Simply press the auto-level button, and the system will automatically assess and adjust the jacks to ensure your RV is perfectly balanced. This mode uses sensors to detect imbalance and activates the hydraulic jacks to level the coach in under a minute. Once leveling is complete, the system automatically retracts the jacks to their resting position, ensuring stability and convenience.

3.2 Manual Mode: Custom Leveling Control

Manual Mode allows users to control the leveling jacks individually for precise adjustments. By using the control panel, you can extend or retract specific jacks as needed. Pressing the LEFT, RIGHT, or REAR buttons enables independent operation, giving you full control over the leveling process. This mode is ideal for fine-tuning the RV’s position on uneven surfaces, ensuring stability and balance without relying on automatic functions.

Safety Information and Precautions

Always follow safety guidelines to avoid injuries and system damage. Hydraulic fluid under high pressure can cause serious harm. Never use the system to support the RV for servicing or tire changes without proper stabilization. Ensure the RV is on level ground and clear of obstructions before operation.

4.1 Essential Safety Guidelines for Using the Level-Up System

Always ensure the RV is on level, solid ground before activating the system. Avoid using the Level-Up System to support the RV for servicing or tire changes. Hydraulic fluid under high pressure can cause severe injury. Never operate the system near open flames or sparks. Only authorized personnel should perform maintenance. Keep children and pets away during operation. Regularly inspect hoses and connections for leaks or damage to ensure safe functionality.

4.2 Avoiding Common Mistakes During Operation

• Always switch between AUTO and MANUAL modes correctly.
• Perform pre-operation checks and avoid over-relying on AUTO MODE for precise leveling.
• Never ignore system alerts, as they indicate potential issues.
• Do not exceed the system’s capacity by using it on soft ground or with an uneven load.
• Always retract jacks before moving the RV to prevent any damage.

Troubleshooting Common Issues

Common issues include hydraulic malfunctions, control panel errors, and oil leaks. Always check fluid levels and system connections. Restart the control panel if it freezes. Inspect hoses for blockages and ensure proper grounding of electrical components. Address oil leaks immediately to prevent system damage. Refer to the manual for detailed diagnostic steps and solutions.

5.1 Diagnosing Hydraulic System Malfunctions

Diagnosing hydraulic malfunctions begins with identifying symptoms like slow operation or fluid leaks. Check the reservoir for proper fluid levels and inspect hoses for blockages or damage. Ensure electrical connections to the pump and control panel are secure. If the system fails to activate, verify the 12V power supply. Avoid guessing repairs; consult the manual for specific troubleshooting steps to prevent further damage and ensure safety. Regular maintenance can prevent many issues.

5.2 Resolving Issues with the Control Panel

If the control panel malfunctions, first ensure the 12V power supply is stable. Check for loose connections and clean the buttons to remove debris. If the panel displays incorrect information, recalibrate the system as outlined in the manual. For unresponsive controls, reset the system by turning it off and on. If issues persist, consult a professional to avoid further damage or safety risks.

Maintenance and Care

Regularly inspect hydraulic hoses and connections for leaks. Check fluid levels and top up as needed. Clean the control panel and ensure all moving parts are well-lubricated.

6.1 Regular Maintenance Tasks for the Level-Up System

Perform regular inspections of hydraulic hoses and connections to prevent leaks. Check the hydraulic fluid level and refill as needed to ensure optimal system performance. Clean the control panel and sensors to maintain accurate leveling readings.

Lubricate all moving parts periodically to reduce friction and wear. Ensure the system is free from debris and obstructions. Schedule professional inspections annually for comprehensive maintenance and system longevity.

6.2 Hydraulic Fluid Management and Refilling

Regularly inspect the hydraulic fluid reservoir to ensure proper levels. Use the recommended hydraulic fluid type to maintain system performance. When refilling, avoid overfilling to prevent system pressure issues. Always refer to the manual for the correct fluid capacity and type. Clean the reservoir cap and surrounding area before refilling to prevent contamination. If the fluid level drops significantly, inspect for leaks and address them promptly to avoid system damage.

Advanced Features and Customization

The Level-Up System offers customization options for specific RV setups, allowing users to adjust settings for optimal performance through its advanced features.
